●Product Features
- Smooth and fresh design, new city temperament.
- The light source, heat dissipation, light distribution and protection of the lamp form a module, modular design, flexible assembly and maintenance.
- The lens is made of high-permeability borosilicate, which effectively avoids UV damage and prolongs life.
- The luminaire can be equipped with a light control or remote controller to achieve intelligent and energy-saving control of the luminaire.
● Applicable place
Urban roads, sidewalks, plazas, schools, parks, courtyards, residential areas, factory areas, and other places where outdoor road lighting is required.
●Technical Parameters
| Model |
AG-L-MZA100
|
| Power |
100W
|
| Input voltage |
AC(85V-265V)/DC(12V/24V) Frequency(50Hz-60Hz)
|
| Power efficiency |
>90%
|
| Light effect |
140LM/W
|
| Lamp efficiency |
>90%
|
| Power factor |
>0.98
|
| Color rendering index |
>70
|
| Color temperature |
2700-7000K
|
| Operating temperature |
-30℃-45℃
|
| Life/protection level |
50,000H/IP65
|
| Weight |
3.5KGS
|
| Product size |
593×285×90mm
|
| Model |
AG-L-MZA150
|
| Power |
150W
|
| Input voltage |
AC(85V-265V)/DC(12V/24V) Frequency(50Hz-60Hz)
|
| Power efficiency |
>90%
|
| Light effect |
140LM/W
|
| Lamp efficiency |
>90%
|
| Power factor |
>0.98
|
| Color rendering index |
>70
|
| Color temperature |
2700-7000K
|
| Operating temperature |
-30℃-45℃
|
| Life/protection level |
50,000H/IP65
|
| Weight |
4.8KGS
|
| Product size |
679×285×90mm
|
| Model |
AG-L-MZA200
|
| Power |
200W
|
| Input voltage |
AC(85V-265V)/DC(12V/24V) Frequency(50Hz-60Hz)
|
| Power efficiency |
>90%
|
| Light effect |
140LM/W
|
| Lamp efficiency |
>90%
|
| Power factor |
>0.98
|
| Color rendering index |
>70
|
| Color temperature |
2700-7000K
|
| Operating temperature |
-30℃-45℃
|
| Life/protection level |
50,000H/IP65
|
| Weight |
6KGS
|
| Product size |
765×285×90mm
|
| Model |
AG-L-MZA250
|
| Power |
250W
|
| Input voltage |
AC(85V-265V)/DC(12V/24V) Frequency(50Hz-60Hz)
|
| Power efficiency |
>90%
|
| Light effect |
140LM/W
|
| Lamp efficiency |
>90%
|
| Power factor |
>0.98
|
| Color rendering index |
>70
|
| Color temperature |
2700-7000K
|
| Operating temperature |
-30℃-45℃
|
| Life/protection level |
50,000H/IP65
|
| Weight |
6KGS
|
| Product size |
851×285×90mm
|
| Model |
AG-L-MZA300
|
| Power |
300W
|
| Input voltage |
AC(85V-265V)/DC(12V/24V) Frequency(50Hz-60Hz)
|
| Power efficiency |
>90%
|
| Light effect |
140LM/W
|
| Lamp efficiency |
>90%
|
| Power factor |
>0.98
|
| Color rendering index |
>70
|
| Color temperature |
2700-7000K
|
| Operating temperature |
-30℃-45℃
|
| Life/protection level |
50,000H/IP65
|
| Weight |
4.8KGS
|
| Product size |
937×285×90mm
|
